Description

The DFM-1616 is an I/O expansion module for the system controller DSC-1616E, Access System Manager (ASM-24E), enteliBUS® Controller (eBCON) and enteliBUS Manager (eBMGR). It provides an additional 16 universal inputs and 16 analog outputs. The DFM-1616 is a LINKnet device and relies on its NET1 port to communicate to its parent controller.

Application

The DFM-1616 provides additional I/O for the DSC-1616E, ASM-24E, eBCON and eBMGR. Up to two I/O modules may be added; this additional I/O is programmed within the parent DSC-1616E in the same manner as local I/O.

When combined with up to two DFM-1616 I/O modules, the DSC-1616E forms a high-density I/O controller intended to
fit a range of central plant applications requiring up to 48 inputs and 48 outputs. This type of system is also suited for elevator control.

Features

16 universal inputs and 16 analog outputs

Easy-to-mount housing

Hand / Off / Auto (HOA) switches with position feedback on all outputs

Supports communicating on LINKnet

Firmware can be flash loaded over the network

Tri-colored status LEDs on all outputs

Specifications

Inputs

Universal Inputs (10-bit) supporting: 0-5 VDC
0-10 VDC
10 kΩ Thermistor
4-20 mA
Dry Contact (using the 10 kΩ Thermistor jumper setting)

Outputs

16 Analog Outputs (0-10 VDC, 8-bit), software configured as analog or binary

Device Addressing

Set via DIP switch and jumpers

Connectors

Removable screw-type terminal connectors

Wiring Class

Class 2
