Designed for use where space is limited
Interrupt/non interrupt in one unit
LED status indication (Yellow - Fault, Green - Polling, Red - Alarm)
DIN Rail mountable
The VES Mini Monitor Module, part no VF5608-00, is a loop-powered device, which
incorporates a monitored input circuit for connection to switches. The module is supplied in a small housing designed to ﬁt into an electrical box, or to be DIN Rail mounted.
It is designed to monitor the state of one or more single pole, volt free contacts connected on a single pair of cables and to report the status to Apollo compatible analog control equipment.
The VES Mini Monitor Module, has an optional priority interrupt facility to give fast
response and can be ﬁtted in an electrical box behind a pull station. This option is selected via the eighth section of the DIL switch.
Please note: When the eighth section of the DIL switch is changed, the VES Mini Monitor Module will change the type code it sends to the panel.
